GLAZED UNITS WITH WARM EDGE

ABOUT GLAZED UNITS WITH WARM EDGE

T Grup Cam‘s Glazed Units with Warm Edge technology enhances thermal insulation and energy efficiency by reducing heat loss at the edges of insulated glass units. Traditional aluminum spacers conduct heat, leading to cold bridges and increased energy consumption. Our warm edge spacers, made from high-performance insulating materials, minimize heat transfer, ensuring better thermal efficiency and reduced condensation risk.

Benefits:

✅ Improved Thermal Insulation – Reduces heat loss and enhances energy efficiency.
✅ Condensation Reduction – Minimizes moisture buildup on the glass edges.
✅ Higher Comfort Levels – Eliminates cold drafts near windows.
✅ Eco-Friendly Solution – Contributes to lower carbon emissions and sustainable construction.

ADVANTAGES

Reduction of the linear heat leakage bridge on the edges of the glass unit

Minimizes linear heat loss at the glass edges for improved insulation.

Limitation of condensation of the edges of the glass unit

Reduces edge condensation, ensuring clearer and more durable glass.

Warm edge criterion according to EN ISO 10077-1

To the time of establishing clear criteria enabling the definition of the warm edge concept, many spacer bars in glass units were sold on the market, which were indeed warmer than aluminium bars however had incomparably worse properties than correct solutions. According to this bars with improved design standard parameters are those, in which the spacer bar fulfils the following inequality:

Σ (diλi) ≤ 0,007 W/K

where:

di – thickness of partition material

λi – television of conductivity of material in W/mK

Example: 2(d1λ1) + (d2λ2) ≤ 0,007 W/K

The table below shows how particular types of bars fulfill the raised criterion:

Types of barsValue ∑ (di x λi)

EN ISO 10077-1

Qualification assessment

of spacer bar as “warm edge”

Aluminium0,1120negative
Stainless steel
Chromatech		0,0052positive
Chromatech Ultra0,0026positive
Termo TGI0,0020positive
Swisspacer Advance0,0019positive
Swisspacer Ultimate0,00002positive
Multitech G0,00002positive


PROCESSING AND MARKING OF WARM EDGES

UgConstruction of glazed units

Window Frame

Type of spacer barPsi factor
1,14/16/4T ArPVCAluminium0,0653
0,74T/12/4/12/4T ArPVCAluminium0,0663
1,14/16/4T ArPVCStainless steel – Chromatech0,0511
0,74T/12/4/12/4T ArPVCStainless steel – Chromatech0,0501
1,14/16/4T ArPVCTermo – TGI0,0401
0,74T/12/4/12/4T ArPVCTermo – TGI0,0381
1,14/16/4T ArPVCChromatech Ultra0,0391
0,74T/12/4/12/4T ArPVCChromatech Ultra0,0371
1,14/16/4T ArPVCSwisspacer Advance0,0391
0,74T/12/4/12/4T ArPVCSwisspacer Advance0,0371
1,14/16/4T ArPVCSwisspacer Ultimate0,0321
0,74T/12/4/12/4T ArPVCSwisspacer Ultimate0,0301
1,14/16/4T ArPVCMultitech G0,0311
0,74T/12/4/12/4T ArPVCMultitech G0,0291
1,14/16/4T ArWoodAluminium0,0713
0,74T/12/4/12/4T ArWoodAluminium0,0763
1,14/16/4T ArWoodStainless steel – Chromatech0,0531
0,74T/12/4/12/4T ArWoodStainless steel – Chromatech0,0541
1,14/16/4T ArWoodTermo – TGI0,0401
0,74T/12/4/12/4T ArWoodTermo – TGI0,0391
1,14/16/4T ArWoodChromatech Ultra0,0391
0,74T/12/4/12/4T ArWoodChromatech Ultra0,0381
1,14/16/4T ArWoodSwisspacer Advance0,0391
0,74T/12/4/12/4T ArWoodSwisspacer Advance0,0371
1,14/16/4T ArWoodSwisspacer Ultimate0,0311
0,74T/12/4/12/4T ArWoodSwisspacer Ultimate0,0291
1,14/16/4T ArWoodMultitech G0,0301
0,74T/12/4/12/4T ArWoodMultitech G0,0281
1,14/16/4T ArAluminiumAluminium0,0802
0,74T/12/4/12/4T ArAluminiumAluminium0,1102
1,14/16/4T ArAluminiumStainless steel – Chromatech0,0681
0,74T/12/4/12/4T ArAluminiumStainless steel – Chromatech0,0661
1,14/16/4T ArAluminiumTermo – TGI0,0491
0,74T/12/4/12/4T ArAluminiumTermo – TGI0,0441
1,14/16/4T ArAluminiumChromatech Ultra0,0481
0,74T/12/4/12/4T ArAluminiumChromatech Ultra0,0431
1,14/16/4T ArAluminiumSwisspacer Advance0,0471
0,74T/12/4/12/4T ArAluminiumSwisspacer Advance0,0421
1,14/16/4T ArAluminiumSwisspacer Ultimate0,0361
0,74T/12/4/12/4T ArAluminiumSwisspacer Ultimate0,0311
1,14/16/4T ArAluminiumMultitech G0,0351
0,74T/12/4/12/4T ArAluminiumMultitech G0,0301



STANDART OFFER

Type of spacer barColourWidths
Termo TGIRAL

grey 7035, 7040;

brown 8003, 8016;

black 9005;

white 9016;

8, 10, 12, 14, 15, 16,

18, 20, 22, 24

Stainless steel Chromatechnatural8, 10, 12, 14, 15, 16, 18, 20
Chromatech UltraRAL

grey 7035, 7040;

brown 8003, 8016;

black 9004;

white 9016;

8, 10, 12, 14, 16

18, 20, 22, 24

Swisspacer AdvanceRAL
light grey 7035;
light brown 8003;
black 9005;
white 9016;

10, 12, 14,

15, 16, 18, 20

Swisspacer UltimateRAL
light grey 7035;
black 9005;		10, 12, 14, 16, 18
MULTITECH Glight grey;
black;		10, 12, 14, 16, 18

Offer avalaible for request with Sales Department

Type of spacer barColourWidths
Stainless steel Chromatechblack 90058, 10, 12, 14, 15, 16, 18, 20
Swisspacer AdvanceRAL

light grey 7035; light brown 8003; black 9005; white 9016;

8, 11, 22, 24, 27

RAL

titanium (grey 9023); dark brown 8014; sulfuric 1016;

yellow-green 6018; beige-brown 1011; pastel yellow 1034;

grassy 6010; sapphire 5003; iridescent green 6026;

brown-green 7013; beige 1001; ivory 1015; red-brown 8012;

8, 10, 11, 12, 14, 15, 16, 18, 20, 22, 24, 27
Swisspacer Ultimate

RAL

light grey 7035; black 9005;

8, 11, 15, 20, 22, 24, 27, 32, 36

RAL

titanium (grey 9023); white 9016; sapphire 5003; light brown 8003;

dark brown 8014; sulfuric 1016; yellow-green 6018; iridescent green 6026;

brown-green 7013; beige 1001; beige-brown 1011; pastel yellow 1034;

grassy 6010; ivory 1015; red-brown 8012;

8, 10, 11, 12, 14, 15, 16, 18, 20, 22, 24, 27, 32, 36
MULTITECH Glight grey; black;8, 15, 20, 22, 24
dark grey; white;8, 10, 12, 14, 15, 16, 18, 20, 22, 24

We constantly modify our manufacturing processes and change habits to limit the negative effect on the environment.

In order to facilitate the changes, we have adopted ISO 14001, the worldwide management system for environmental protection.
